Description
T380 Skid steer loader is built for tough jobs in tight spaces. It’s great for digging, hauling, and trenching on farms, in gardens, or warehouses. Plus, it works with attachments like Root Grapples, Stump Grinders, and Augers, making it the go-to machine for versatility and power.
| ERFORMANCE | |
| Engine Power（HP) | 23 |
| Speed- standard(KM/H) | 6.7 |
| Track type | 180*72 |
| Rated loading capacity(KG) | 380 |
| Lifting type | Radial lift |
| Total cycle time(S) | 9.2 |
| Bucket capacity(m³） | 0.17 |
| System pressure（bar） | 170 |
| Hydraulic pump output flow（L/min） | 38 |
| Starting battery | 12V |
| Hydraulic oil tank（L) | 30 |
| Fuel tank（L) | 20 |
| Wight without bucket(KG) | 700 |
| DIMENSION | |
| Overall operating height(MM) | 2510 |
| Height to bucket hinge pin(MM) | 1940 |
| Height to top of cab(MM) | 1350 |
| Height to bottom of level bucket(MM) | 1800 |
| Overall length without bucket(MM) | 1820 |
| Overall length with bucket(MM) | 2200 |
| Dumping angle at maximum height | 40 |
| Dumping height(MM) | 1510 |
| Dumping reach(MM) | 460 |
| Rollback of bucket on ground | 30 |
| Rollback of bucKet at full heirht | 105 |
| Wheelbase(MM) | — |
| Ground clearance(MM) | 186 |
| Angle of departure | 26 |
| Turning radius front without bucket(MM) | 800 |
| Front turning radius with bucket(MM) | — |
| Rear turning radius(MM) | — |
| Track width(MM) | — |
| Width(MM) | 960 |
| Bucket width(MM) | 1000 |
1. Compact design, small size, compact structure, able to easily enter and exit narrow work spaces.
2. Strong power, equipped with an efficient engine, providing powerful lifting and traction
3. Multi functionality, can replace various accessories according to different job .requirements, such as buckets, grab buckets, fork frames, road sweepers, etc
4. Operational flexibility, using a two handed control system, enables operators to easily control the movement and operation of equipment.
5. High maneuverability, with a small turning radius, suitable for complex and narrow working environments.
6. High efficiency and safety, equipped with comprehensive safety equipment to ensure the safety of operators.
