Heavy-Duty Construction King: 33 Ton Crawler Excavator CT330
The company’s main products cover various types of small excavators, skid steer loaders and diverse attachments, which are widely used in agriculture, municipal administration, construction and logistics fields.
Recruiting Agents Globally:
Suitable for businesses/dealers, starting with one unit for overseas warehouses.
Customized for construction projects, not available for retail.
Inventory located at a warehouse near you, ensuring fast delivery and a comprehensive range of accessories.
Customer service is available 24/7.
Fill in your information, receive a quote, and become our agent!
Description
Built to conquer the world’s most grueling job sites, the 33 Ton Crawler Excavator CT330 is the ultimate flagship of our heavy-duty series. This 33 Ton Crawler Excavator is designed for extreme productivity in large-scale mining, quarrying, and high-volume earthmoving. With its massive operating weight and industry-leading bucket capacity, the CT330 delivers the unrelenting force and rock-solid stability required to move mountains of material while maintaining the lowest cost per ton in its class.
| SPECIFICATIONS | |
| Bucket Capacity（m³） | 1.6 |
| Swing Speed（rmp） | 0-11 |
| Gradeablity（°） | 35 |
| Max.Bucket Digging Force（KN） | 244 |
| Max.Arm Digging Force（KN） | 200 |
| Engine Model | 6CTA8.3 |
| Power/revolution speed(KW/rmp) | 194/2200 |
| Tire Model | – |
| System Pressure(MPa) | 35 |
| MACHINE SIZE | |
| Dimension Length*Width*Height(mm) | 11015*3200*3168 |
| Cabin Height(mm) | 3168 |
| Axle Base(mm) | 3800 |
| Wheel(track)Distance(mm) | 2590 |
| Minimum Ground Clearance(mm) | 470 |
| Tail Swing Radius(mm) | 3480 |
| WORKING RANGE | |
| Max. Digging Height（mm） | 10491 |
| Max Dumping Height（mm） | 7625 |
| Max. Digging Depth（mm） | 6437 |
| Max. Vertical Digging Depth（mm） | 5831 |
| Min. Digging Radius（mm） | 10709 |
| Max. Swing Radius（mm） | 3643 |
Why Choose the Certeg CT330 for Large Projects?
At Certeg Machinery, the CT330 is built using the highest grade high-tensile steel and undergoes a 96-hour continuous heavy-load test cycle. We provide a full 2-year industrial warranty and global rapid-response spare parts support to ensure your operation never stops.
Common Applications
Large-scale open-pit mining and quarrying.
Massive highway, dam, and bridge construction.
Major land reclamation and industrial site preparation.
Heavy material handling in large-scale port operations.
