Description
CTB30-25: The Ultimate 75kW Backhoe Loader for Heavy-Duty Projects
CERTEG CTB30-25, our premier heavy-duty backhoe loader, engineered for the most demanding and large-scale projects. This machine is a true titan on the job site, combining immense power with sophisticated hydraulic control to deliver unparalleled productivity. At its heart lies a formidable 75 kW (100 HP) Yuchai engine, powering a robust Four-Wheel Drive (4WD) system. With its massive 1.0 m³ loader bucket and an exceptional 4000 mm digging depth, the CTB30-25 is the definitive choice for heavy construction, large-scale earthmoving, quarrying, and major infrastructure development. When your project requires the absolute pinnacle of power, reach, and reliability, the CTB30-25 is the answer.
| Category | Parameter | Value |
| Overall Dimensions | Overall Dimensions (L×W×H) | 7070 × 2300 × 3769 mm |
| Cab Roof Height | 2900 mm | |
| Wheelbase | 2250 mm | |
| Axle Track | 1640 mm | |
| Min. Ground Clearance | 300 mm | |
| Performance | Total Operating Weight | 7600 kg |
| Drivetrain | Four-Wheel Drive (4WD), Full Hydraulic | |
| Rated Load | 2000 kg | |
| Max. Speed | 22 km/h | |
| Max. Gradeability | 30° | |
| Loader Specs | Loading Bucket Capacity | 1.0 m³ |
| Max. Articulated Height of Bucket | 3400 mm | |
| Bucket Discharge Height | 2795 mm | |
| Bucket Discharge Distance | 1048 mm | |
| Loading Lift Capacity | 25 kN | |
| Max. Tractive Force | 39 kN | |
| Max. Breakout Force | 38 kN | |
| Backhoe Specs | Backhoe Bucket Capacity | 0.3 m³ |
| Backhoe Discharge Height | 3878 mm | |
| Max. Digging Depth | 4000 mm | |
| Max. Digging Radius | 5688 mm | |
| Bucket Swing Angle | 190° | |
| Bucket Digging Capacity | 46 kN | |
| Dipper Stick Digging Capacity | 31 kN | |
| Engine | Engine Model | Yuchai |
| Rated Power | 75 kW / 100 HP | |
| Rated Speed | 2400 r/min | |
| Hydraulic System | System Pressure | 18 MPa |
| System Flow | 120 L/min | |
| Brakes & Tires | Tire Size | 16/70-20 |
| Front Wheel Pressure | 0.22 MPa | |
| Rear Wheel Pressure | 0.20 MPa | |
| Service Brake | Air-over-hydraulic disc on 4 wheels | |
| Parking Brake | Manual | |
| Fluid Capacities | Fuel Tank | 70 L |
| Transmission Oil | 25 L |
Dominant 100 HP Power & All-Terrain Drivetrain
The foundation of the CTB30-25’s immense capability is its high-performance 75 kW (100 HP) Yuchai engine, delivering the massive torque required for aggressive digging and heavy lifting. To effectively translate this power into unstoppable performance, the machine is equipped with a state-of-the-art full hydraulic drivetrain.
High-Capacity, High-Productivity Front-End Loader
Harnessing this incredible power, the front-end loader is designed for maximum productivity and material handling efficiency. It boasts an immense 38 kN breakout force to power through any stockpile.
Extended-Reach, Deep-Digging Backhoe
Equally impressive, the rear-mounted excavator arm is a master of reach and power, making it ideal for deep excavation, long-range trenching, and complex site preparation.
Ideal Applications
The robust construction and powerful performance of this 7.6 ton backhoe loader make it ideal for:
Large-Scale Construction & Site Development
Roadbuilding and Municipal Projects
Major Utility and Pipeline Trenching
Quarrying and Bulk Material Stockpiling
Heavy-Duty Rental Fleets
