Description
CTB08-12: The Ultimate 4WD Backhoe Loader for All-Terrain Performance
CERTEG CTB08-12, a robust and versatile backhoe loader engineered to deliver exceptional power and all-terrain capability. Built to handle the toughest jobs, this machine combines the strength of a powerful loader with the precision of an agile excavator, all powered by a reliable 4-Wheel Drive system. The CTB08-12 is the definitive choice for contractors who require a single, dependable machine for demanding construction, agriculture, and municipal maintenance projects. Its powerful engine and heavy-duty construction ensure maximum productivity and an outstanding return on investment.
| Category | Parameter | Value |
| Overall Dimensions | Overall Dimensions (L*W*H) | 5100 * 1350 * 2580 mm |
| Wheelbase | 1910 mm | |
| Axle Track | 1100 mm | |
| Min. Ground Clearance | 250 mm | |
| Performance | System Pressure | 16 MPa |
| Overall Weight | 2800 kg | |
| Max. Travel Speed | 20 km/h | |
| Max. Gradeability | 25° | |
| Min. Turning Radius | 3000 mm | |
| Loader Specs | Max. Dumping Height | 2200 mm |
| Max. Dumping Distance | 800 mm | |
| Bucket Width | 1300 mm | |
| Bucket Capacity | 0.4 ㎥ | |
| Max. Lifting Height | 3000 mm | |
| Max. Breakout Force | 28 kN | |
| Bucket Cycle Time | 12 s | |
| Backhoe Specs | Max. Digging Depth | 1500 mm |
| Digging Dumping Height | 1500 mm | |
| Max. Digging Radius | 2000 mm | |
| Bucket Width | 350 mm | |
| Bucket Capacity | 0.08 ㎥ | |
| Max. Digging Height | 2600 mm | |
| Max. Digging Force | 25 kN | |
| Swing Angle | 180° | |
| Engine | Model | Yunnei 490 |
| Type | 4-Stroke | |
| Rated Power | 27 kW (37 HP) | |
| Rated Speed | 2400 r/min | |
| Cylinder No. – Bore | 4 – 90 mm | |
| Drivetrain | Transmission Type | Powershift, Fixed Shaft |
| Gears | 2 Forward, 2 Reverse | |
| Torque Converter Model | ZL28F | |
| Drive Type | 4-Wheel Drive (4WD) | |
| Steering & Axle | Steering Type | Articulated Full Hydraulic |
| Steering Angle | 33° | |
| Axle Model | 130 Ling | |
| Brakes & Tires | Tire Specification | 8.25-16 |
| Tire Pressure (Front/Rear) | 250 KPa | |
| Service Brake | Oil-actuated Drum Brake | |
| Parking Brake | Manual | |
| Braking Distance | 300 mm | |
| Fluid Capacities | Fuel Tank Capacity | 20 L |
| Hydraulic Oil Tank Capacity | 20 L |
Superior All-Terrain Drivetrain
The CTB08-12 is powered by a reliable 27 KW (37 HP) Yunnei 490 engine, delivering consistent and efficient power for all operations. Engineered for heavy-duty material handling, the front-loader makes quick work of any task. With a maximum breakout force of 28 KN, it’s built to perform.
Durable Construction & Operator-Focused Design
The rear-mounted excavator arm offers the perfect balance of power and precision for digging, trenching, and excavating.
Ideal Applications
The versatility and 4WD capability of this compact 4×4 backhoe make it perfect for:
Construction on undeveloped or muddy sites
Farming, agriculture, and forestry work
Landscaping on varied or hilly terrain
Municipal maintenance in all seasons
General earthmoving and material handling
