SKID STEER LOADER PARTS

Specification Unit 3500 7000 10000 Max. Hole Diameter mm 500 700 900 Oil Flow L/min 50-75 55-115 70-150 Operating Pressure MPa 16 16 16 Max. Torque N.m 3500 7000 10000 Overall Length mm 1160 1160 1160 Overall Width mm 1050 1050 1050 Overall Height mm 490 490 490 Weight kg 240 260 320

Specification Unit Value Weight kg 120 Operating Pressure MPa 16 Overall Length mm 1240 Overall Width mm 230 Overall Height mm 410

Specification Unit Value Spear Length mm 1300 Spear Diameter mm 50 Overall Length mm 1310 Overall Width mm 1150 Overall Height mm 560 Weight kg 90

Specification 530 680 Operating Weight kg 120 250 Operating Pressure MPa 9-12 11-14 Oil Flow L/mm 25-50 40-70 Impact Frequency BPM 600-1100 500-900 Tool Diameter mm 53 68 Overall Length mm 570 570 Overall Width mm 1202 1660 Overall Height mm 1326 1660

Specification Unit 30 Total Bucket Capacity m³ 0.3 Loading Capacity m³ 0.3 Max. Discharge Capacity m³ 0.3 Mixing Time s ≤ 50 Mixing Speed r/min 70 Operating Pressure MPa 16-21 Oil Flow L/min 75-140 Weight kg 380 Overall Length mm 1250 Overall Width mm 1030 Overall Height mm 950

Specification Unit Value Cutting Width mm 1500 Working Angle ° 90 Operating Pressure MPa 16 Oil Flow L/min 50-125 Weight kg 300 Overall Length mm 3480 Overall Width mm 442 Overall Height mm 602

Specification Unit 66″ 72″ 84″ Working Width mm 1680 1830 2130 Working Height mm 720 720 720 Working Length mm 970 970 970 Weight kg 300 330 360 Angling Angle ° ±22 ±22 ±22 Operating Pressure MPa 16 16 16

Specification Unit Value Working Width mm 1698 Swing Amplitude mm 110 Operating Pressure MPa 16 Weight kg 670 Overall Length mm 1326 Overall Width mm 1540 Overall Height mm 788
